Features
- Auto focus control via 0-10V or EtherCAT
- 4-Color LED lamps to monitor interior status
- Optimized optical configuration and smooth gas circuit
- Optimized X/Y alignment knob to facilitate beam alignment
- Real-time status of the cutting head could be accessed at the mobile APP or the CNC controller
- Real-time monitoring to focus on the position and ready status of the bottom cover glass
- Real-time monitoring of the temperature of the top/bottom cover glass, focus lens, and cavity
- Real-time monitoring of cutting gas pressure and cavity pressure
- USA/Germany/Japan-made fused silica raw lens material. High power rating of the lens by 12000W.
- Standard QBH/QD (LLK-D)/G5 interfaces to work with different fiber lasers
Technical Data
Wavelength | 1080 nm |
Fiber Interface | QBH, QD, G5 |
Power Rating | 8000W |
NA max | 0.13 |
Collimation Length | 100 mm |
Focusing Length | 150 mm/200 mm |
Auto Focus Range | -26 mm +16 mm (FL150); -52 mm +32 mm (FL200) |
Cover Glass | |
Top | 24.9 * 1.5 mm |
Middle/Bottom | 37 mm * 7 mm |
Assist Gas Pressure | 25 bar |
Weight | 8.2 kg |
Operating Temperature | 5 to 55°C |
Humidity | 30% to 95% without condensation |
*Specifications are subject to change without notice.
