Features
Up to 6KW Output from CW Single Module Series
- Better beam quality compared to multi-module lasers
- Greatly improved efficiency
Excellent Material Processing Performance
- Cuts thin sheet quickly
- Capable of processing thicker materials
Compact Design, Maintenance Free
- Highly integrated system with modular design
- Easy maintenance that significantly reduces TCO
Smaller Size with Higher Stability
- >60% reduction in volume
- Higher flexibility when integrated into your system
High-Level Vertical Integration
- All key components are designed and produced in-house
- Strict quality control, high consistency, and reliability
Technical Data
Optical Specifications
Nominal Power | 2000W | 3000W |
Mode of Operation | CW/Modulated |
Polarization | Random |
Power Tunability | 10 to 100% |
Wavelength | 1080 ± 10 nm |
Power Stability | ±1 % |
Laser Beam Quality M2, BPP | 1.1 to 1.5 mm x mrad(50um QBH) 2.8 to 3.6 mm x mrad(100um QBH) |
Modulation Frequency | ≤ 5kHz |
Preview Red Light Power | 200μW |
Fiber Delivery System
Interface | QBH(LOC) |
Length | 15 m standard, other lengths optional | 20 m standard, other lengths optional |
Diameter | 50(100/200) μm |
Bending Radius | 200 mm |
Electrical Ratings
Supply Voltage | 400VAC (-15% to +10%) 3-phase |
Other Specifications
Operating Temperature | +10 to +40°C |
Storage Temperature | -10 to +60℃ |
Humidity | 10 to 85% |
Cooling Method | Water Cooling |
Cooling Medium | Distilled Water/Glycol Antifreeze |
Dimension | 482.6×950×193 mm |
Weight | 72(±3) kg | 80(±3) kg |
