Specifications
Mild Steel Cut Capacity | Dross free Production pierce Maximum cutting capacity | 38 mm (1-1/2") 50 mm (2") 80 mm (3.2") |
Stainless Steel Cut Capacity | Production pierce Maximum pierce** Severance | 45 mm (1-3/4") 75 mm (3") 80 mm (3.2") |
Aluminum Cut Capacity | Production pierce Severance | 45 mm (1-3/4") 80 mm (3.2") |
Speed (Mild Steel) | Book specification at the highest output current | 12 mm (1/2") 4430 mm/m (170 ipm) |
Cut Angle | ISO 9013 range* | 2-4 |
Weldability | Ready to weld | |
Process Gases By Material (Plasma/Shield) | Mild Steel | 02/Air, 02/02 Ar/Air |
Stainless Steel | H35/N2, N2/N2, H35-N2/N2, F5/N2 Ar/Air, Ar//N2 | |
Aluminum | H35/N2, Air/Air, H35-N2/N2 Ar/Air, Ar//N2 | |
Process Amps (Cutting) | Not all processes are available for all materials | 30-400 |
*ISO 9013 is a standard that defines the cut quality of thermally cut parts. The lower the range (range 1 is the lowest), the smaller the angle on the cut face. A cut angle in range 4 is better than one in range 5.
**Maximum pierce requires the use of an autogas console and controlled motion process. See technical documentation for details.
